Mobile Conference Projector Laptop Tripod Stand

Mobile Conference Projector Laptop Tripod Stand

Details
15'' motorized flip-backwards monitor Conference display solution - D series motorized foldable monitor with keyboard & mouse
Category
Old Products
Share to
Send Inquiry
Description
Technical Parameters

To continuously increase the administration process by virtue of the rule of 'sincerely, good religion and excellent are the base of company development', we commonly absorb the essence of linked goods internationally, and continually build new solutions to fulfill the requires of shoppers for motorized retractable nameplate, hidden screen lift, table receptacle. We improve the human resource management system, establish the company's human resource information database, build the information sharing mechanism and management synergy mechanism of human resources, and form a talent resource flow system within the company. In talent development, on the one hand, the company needs talents from the market and recruits talents urgently needed by enterprises from the society. On the other hand, activate internal talents and introduce the competition mechanism of survival of the fittest to make young talents stand out. Our company actively assumes social responsibilities, condenses into collective energy with its own individual strength, and makes contributions to society.

FZ-15D conference foldable LCD screen (flips up & backward monitor) with keyboard and mouse. The screen size is 15.6 inches, the capacitive touch screen is optional, besides, host, touch screen, keyboard, mouse are optional as well. The tilting angle is motorized adjustable 0-110°. FZ-15D conference foldable LCD display comes with a appearance of the closeable notebook computer with keyboard and mouse, and it is used like a hidden integration device. The monitor can be automatically hidden inside the tabletop when it is not under use.

It provides an efficient solution and enjoyable experience of conference communication, especially for sharing the enormous data information.It also build us the modern and energy saving surroundings of paperless conference system. Flip up monitor with keyboard and mouse,to meet the users' requirement of information input and visit. Press the UP button of the LCD monitor flip up device (or use remote control), the monitor will be automatically flip up with an angle of 105 degree from the desktop. At the meanwhile, the mouse and keyboard will be rose to the same level with the desktop. The users can control easily the keyboard and mouse on the table. When finish using,the whole product will be automatically hidden inside the table once press the DOWN button.

FZ-15D (3)FZ-15D (2)FZ-15D (1)FZ-15D (4)


Product Parameters:

1. Product model: FZ-15D

2. Keyboard & mouse: famous brand wireless keyboard and mouse or wired keyboard and mouse can be selected according to user needs.

3. Resolution: 1920*1080

4. Signal interface: HDMI/VGA

5. Panel material: magnesium aluminum alloy, surface treatment includes anodized, brushed or sandblasted

6. Control modes: central control, manual control, professional computer software control, 485 centralized control


Product Features:

1. Integrated with intelligent identification chip set, double protection for more than 30000 times switch closure

2. Stable running, noise is less than 30 dB

3. Motorized adjustable tilting angel 0°~110°

4. The inner loop ball screw drives the main shaft, stable and reliable, the details conform to the ergonomic design, will not cause fatigue if use for a long time

5. The conventional lift, pause, but also with PC power switch button and signal switch button, support VGA, HDMI input

6. Multiple sizes of 15’’, 17’’, 19’’, 22’’, 24’’ are optional

7. Ultra-thin monitor design, only 9MM thickness monitor

8. Hidden design to save space and makes a modern office environment

9. Stable quality, reliable performance with competitive price

10. Made by Aluminum alloy material, which is corrosion resistant, wear-resistant,smooth surface and not easy to scratch.

11. Adopting shielding technology for display circuit, no magnetic interference and nonradioactive to human with environmental protection and great security during using

12. All wired circuits of monitor lift adopt standard double insulation and safety ground connection earth leakage protection, without faradism and leakage with great security

13. Black and sliver color is available


Model No. Dimension Screen Titling or Rotation Angle Display Parameters Interface One-way Running Time Microphone Parameters Signature Display Parameters Technique Power Parameters Drive Method Control Method
FZ-15D Screen Size 15.6'' Adjustable 0°-110° Resolution 1920*1080 USB 2 20s / / Color Sliver/Black Voltage 110/220V Precise screw and micro motor drive- flip up and fold down Screen flip up/fold down, angle adjustment, power on/off can be performed by manual control, centrolized control through RS485.
Screen Thickness 9mm Brightness 300 HDMI 1 Panel Material Aluminium Alloy power consumption <40W
Panel Size 510*392mm Aspect Ratio 16:9 COM 2 Panel Surface Anodized sand brushed/ sandblast finishing
Cutting Size 496*378mm Contrast Ratio 500:1 Keyboard & Mouse wireless
Whole Frame Size 510*392*100mm View Angle 70/70/60/60


[[ContDescription]]



Hot Tags: 15'' motorized flip-backwards monitor, China, suppliers, factory, buy, foldable LCD display, portable LCD display, LCD display lift, Motorized Flip backwards Monitor, conference embedded LCD screen, motorized liftable microphone
