The perfect independent technological innovation system promotes us to always be at the forefront of the field of in table charger, 15 Motorzied Retractable Monitor Combined with Microphone and Liftable Signature Display, audio video box and win the trust and cooperation of customers. Consistent adherance to the high quality, high standards and strict requirements of the products is our company culture. We recognize that professionals in business and product technology are at the heart of the creative process. Our product quality can stand the test of time, we guarantee that every product is carefully developed, and through strict inspection. It is our eternal pursuit to provide customers with first-class products and high-quality services. We will continue to put customers first and develop together. Warmly welcome friends from all walks of life at home and abroad to negotiate and cooperate.
The size of screen equipped on AX-15MF conference monitor lift is 15.6’’, the tilting angle is motorized adjustable 0-40 degree. Host, Touch Screen are optional. AX-15MF conference monitor system has various functions and beautiful appearance, very suitable apply to large-scale presentation & discussion conference center. MF conference display series is available for 15-24 inches screen, using 5 control buttons to control the lifting up & down of monitor, and the the back of the screen is made of toughened glass.
Product Features:
1. The width of panel is 75 mm
2. 10 pints projective capacitive touch HD screen
3. Motorized tilting angle 0-40°
4. 15-24 inches screen for optional
5. Independent buttons for lifting control
6. Screen brightness 300 cd/m2
7. Ultra silence design
8. Using full aluminum alloy as the material for the panel, it has advantages of light, corrosion resistant, wear-resistant,smooth surface and not easy to scratch
9. Motorized by tank chain and mechanical gear, good quality and smooth and quiet when working
10. Hidden design to save more space and makes a modern office environment
11. Ultra thin monitor and machine body, elegant design and save space
12. Works smoothly and quietly, fast
13. With protecting function of LCD monitors by cutting the electricity off automatically
14. Control system: buttons on the panel, remote control, RS232 or RS485 central control..
15. Power plug and voltage could be customized according to user's requirements
Packaging
| Model No. | Dimension | Screen Titling or Rotation Angle | Display Parameters | Interface | One-way Running Time | Microphone Parameters | Signature Display Parameters | Technique | Power Parameters | Drive Method | Control Method | |||||
| AX-15MF | Screen Size | 15.6'' | Adjustable 0°-40° | Resolution | 1920*1080 | USB | 2 | 10s | / | / | Color | Sliver/Black | Voltage | 110/220V | Micro motor with sliding rails and belt wheel on both hand sides | Screen lift up/down, angle adjustment, power on/off can be performed by manual control, centralized control through RS485 or the third-party controlling app by Ethernet. |
| Screen Thickness | 8mm | Brightness | 300 | HDMI | 1 | Panel Material | Aluminium Alloy | Frequency | 50Hz | |||||||
| Panel Size | 435*75*3*R10mm | Aspect Ratio | 16:9 | VGA | 1 | Panel Surface | Anodized sand brushed/ sandblast finishing | power consumption | ＜60W | |||||||
| Contrast Ratio | 700:1 | |||||||||||||||
| View Angle | 85/85/80/80 | |||||||||||||||
