15'' Motorized Flip-fowards Monitor

FZ-15W foldable monitor flips up & forward monitor is equipped 15.6 inches screen, meets the need of one key to suitable tilting angle for watching, touching operation is very flexible, and the capacitive touch screen with is optional. The tilting angle of screen is motorized adjustable 0-80°, the appearance of FZ-15W foldable LCD display is fashionable and upscale, whole machine body is delicate and light, perfect for a variety of conference table styles. The monitor can be automatically hidden inside the tabletop when it is not under use.

W series of electrical foldable LCD screen is a specially design for high-class conference solutions. It provides an efficient solution and enjoyable experience of conference communication, especially for sharing the enormous data information. It also build us the modern and energy saving surroundings for smart conference system. With the FHD touch screen, users can easily and conveniently input and visit the information, without using the mouse and keyboard. Press the UP button of the LCD monitor flip up device (or use remote control), the monitor will be automatically flip up from the desktop. When finish the using, the whole product will be automatically hidden inside the table once press the DOWN button. It is widely use in conference system, video conference system, financial analyzing system, advanced office system, lecture and training room with conference table& computer desk, etc.

Product Parameters:

1. Range of tilting angle: can be adjusted freely between 0°-80°

2. Resolution: 1920*1080

3. Panel material: magnesium aluminum alloy, surface treatment includes anodized and brushed or sandblasted

4. Control modes: Third party central control, button control, 485 centralized control, 232 centralized control

5. Operation mode: Silence running motor with inner circulating screw

Product Feature:

6. integrated intelligent identification chip set, double protection for more than 30000 times switch closure.

7. Stable running, noise is less than 30 dB.

8. The inner loop ball screw drives the main shaft, stable and reliable.

9. The conventional lift, pause, but also with PC power switch button and signal switch button, support VGA, HDMI input.

10. Multiple sizes of 15’’, 17’’, 19’’, 22’’, 24’’ are optional.

11. 15.6,17.3,18.5 touch FHD Screen are available, others can be customized

12. Hidden design to save space and makes a modern office environment

13. Stable quality, reliable performance with competitive price

14. Automatic Control system: buttons, remote control, RS 485 central control

15. Made by Aluminum alloy material, which is corrosion resistant, wear-resistant,smooth surface and not easy to scratch

16. FHD touch screen, modern design and more convenient to control without using mouse and keyboard

17. Adopting shielding technology for display circuit, no magnetic interference and nonradioactive to human with environmental protection and great security during using

18. All wired circuits of monitor lift adopt standard double insulation and safety ground connection earth leakage protection, without faradism and leakage with great security.

19. Black and sliver color is available
