YHJT-22HPZ01 Intelligence Digital Electric Lifting Podium Lectern For Conference Room Church Pulpit



Yihang Technology is located in Wuhan Optics Valley Core Park B, which is the location of sales headquarters and technology research and development center. In addition,the company has sales branches in Beijing, Shanghai, Nanjing and Chengdu, and a production base in Hanchuan city, Hubei Province.



01



large enterprise scale

Efficient and precise processing and testing equipment.



02



Standardized Production

Passed ISO9001 certification and obtained relevant patent certificates.



03



High-Quality Customized Services

No intermediate links, providing one-stop service from design, processing, mold trial to mass production.





YHJT-22HPZ01



Intelligence Digital Electric Lifting Podium Lectern for Conference Room Church Pulpit

YHJT-22HPZ01 smart lectern is full intellectual property rights, mainly used for business presentations, academic exchanges, and work reports. Along with elegant design and the stable full-steel structure, The device consists of a lectern body, a flip angle LCD display and a built-in PC. The lectern can be lifted Max 20cm to accommodate different users . It equipped not only a storage box for small devices like laser pointers, but also a cup holder for convenience of speaker







from left to right:

S1 Ambient light switch

S2 Podium power switch interface

S3 USB input interface 1

S4 USB input interface 2

S5 Double backup microphone pole 1

S6 Dual backup microphone pole 2

S7 Dual backup microphone switch

S8 Lecture timer

S9 Table rise button

S10 Table lower button







from left to right:

HDMI external signal expansion video output interface

HDMI built-in PC video output interface

Table fixed microphone output 1 interface

Table fixed microphone output 2 interface

Computer audio output interface*2

Network input interface

220V Power input socket with fuse

The overall parameters are as follows:
Table height: the lowest table is 990mm, the highest table is 1100mm.
Table lifting thrust: 2000N Stroke: 200mm Load speed: 8.5mm/s
Table size: table length 739mm, table width 500mm.
Display resolution: 1920*1080, 250cd/square meter 10-point capacitive touch screen
Secondary screen size: 12.6 inches
Peripheral location: Dual backup single-pole gooseneck microphones are distributed on both sides, and the built-in PC USB interface is arranged on the table. The main display is in the middle. The water cup holder is located inside the podium and is wall mounted.
Standard pickup distance: 420mm single pole length + 500mm pickup distance.
Equipment maintenance method: post-disassembly maintenance.
Table tilt angle: 5°.
Monitor: 22-inch electric flip-up 10-point touch screen.
Microphone: single pole gooseneck*2.
Ambient light: blue/white.
Base wheel: Fuma wheel*4.
Network: Wired network port.
Built-in PC: CPU: i5-10210U Memory: 8G Hard drive: 256G. (Standard configuration, optional according to user needs)
Interface: expanded HDMI output*1, built-in PC HDMI output*1, 3.5 audio output*1, RJ45 network port input, panel input USB3.0*2.
Coaster: front wall-mounted.
Weight: 65KG (net weight)
The microphone is fixedly installed on the table;
Microphone type: condenser
Microphone response: 40Hz-16KHz
Microphone directivity: cardioid
Microphone output impedance (impedance): 200Ω
Microphone sensitivity: -38dB±2dB
