The Motorized Retractable Nameplate is a cutting-edge digital signing solution designed for modern workspaces. Ideal for secure document signing, this device provides an intuitive, touch-enabled display that makes signing electronic documents quick and efficient. The automated display ensures that the screen retracts smoothly after use, maintaining a clutter-free workspace and protecting the display from damage.This integrated signing system not only enhances the efficiency of document handling but also adds a layer of security by ensuring that signatures are both digitally encrypted and securely stored.
Specification
Display
| Screen size | 7 inch dual sided |
| Matrix type | TFT |
| Resolution | 1024*600 |
| Brightness | 350cd/mf |
| Contrast ratio | 800:1 |
| Aspect ratio | 14:9 |
| View angle | 85/85/85/85 |
| Backlight | 10000 hours |
| Response time | 30(Typ.)(Tr+ Td)ms |
Electronical
| Control | RJ45 |
| Data input | USB2.0 |
| Protocol | RS485 |
| Power supply | AC 220V~250V 50~60Hz |
| Power consumption ! | < 30W |
Mechanism
| Cover plate | anodized aluminium |
| Finishing | black/ silver, matt/brushed |
| customization available | |
| G.W. | 20kgs |
| Packing dimension | 720* 795*185 mm |
| Temperature | working 0°C~ + 50°C,storage -20°C~+ 60°C |
| Humidity | working≤90%, storage≤90% |
Accessory
| power cord | RS485 control cable |
Control
| Manual | RS485 | antenna(optional) |
